The plug and tube components are manufactured by using biocompatible stainless steel with the highest strength available providing durability to any biomechanical stress.
The plug component features a special mushroom design that prevents the tube from disengaging once the patient is in mouth wide open position. |
|
|
|
The housing components are designed to be embedded in the acrylic splint: featuring a laser welded wire throughout that can be easily bent to enhance the resin retention and avoid unwanted detachment. The outer part presents a main screw to accommodate the connection screws binding the ends of the hinges. |
| |
| |
 |
The multi-purpose tool can be used as screwdriver or a wrench to tighten the square head screws into the housing. |
|
| |
 |
The plug has an inner advancer screw that can be activated by using the wrench in the direction indicated by the laser marked
arrow: each ¼ activation produces 0.1 mm advancement. The maximum elongation is 7mm on both sides. |
|
| |
| |
| The assortment includes all the components for an easier and more precise construction of the anti-snoring appliance with telescopic adjustable arms |
 |
A5100-07
Kit includes 1 right telescopic arm and 1 left telescopic arm, 4 housings with steel wire for acrylic, 4 fixing screws for housing and 1 wrench for activation.
For the assembly of 1 telescopic advancer. |
A5100-17
Package of 10 kits A5100-07.
For the assembly of 10 telescopic advancers. |
| |
|
| |
 |
A5101-00
Pack of 4 fixing screws for housing and 1 wrench for activation. |
|
| |
 |
A5101-01
Pack of 4 housings with steel wire for acrylic, 4 fixing screws for housing and 1 wrench for activation. |
|
 |
| |
